PHYSICAL CHARACTERISTICSDimensions6.5 in. H x 2.6 in. W x 3.9 in. D / 16.5 cm H x 6.7 cm W x 9.8 cm DWeight5.7 oz. / 161.9 gInput Voltage Range4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power SupplyOperating Current at Nominal Voltage (5.0V)340 mA (typical)Standby Current (Idle) at Nominal Voltage (5.0V)150 mA (typical)ColorTwilight BlackSupported Host InterfacesUSB, RS232, TGCS (IBM) 46XX over RS485Keyboard SupportSupports over 90 international keyboardsElectronic Article SurveillanceCompatible with Checkpoint EAS deactivation systemUser IndicatorsDirect Decode Indicator, Good Decode LEDs, rear view LEDs, beeper (adjustable tone and volume)PERFORMANCE CHARACTERISTICSLight SourceAiming Pattern: circular 617nm amber LEDIllumination(2) 660nm red LEDsImager Field of View36.1 H x 22.6 V nominalImage Sensor1280 x 800 pixelsMinimum Print Contrast15% minimum reflective differenceSkew/Pitch/Roll ToleranceSkew: 60Pitch: 60Roll: 360DECODE CAPABILITIES1DCode 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)2DPDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes, SecurPharm, DotCode, Dotted DataMatrixOCROCR-A, OCR-B, MICR, US Currency
