UTx318M Infrared Medium-Range Thermal Monocular
$1,599.00
Add to Cart
Overview
UTx318M Enhanced Clarity for Every Mission
Step up your game with the UTx318M—a powerful thermal monocular that delivers exceptional clarity and detail. Engineered for outdoor exploration, search and rescue, and security operations, the UTx318M is your dependable companion in the field.
The UTx318M features an 18mm lens, offering a versatile range for mid-distance detection, perfect for spotting animals, finding heat sources, or conducting perimeter scans. With a thermal sensitivity of ≤35mK, it captures even the smallest temperature differences, ensuring nothing escapes your sight.
The monocular includes stadiametric ranging, which enables you to estimate distances based on known object sizes. While laser range finding provides pinpoint precision, stadiametric ranging is a practical, lightweight solution for dynamic environments where speed and simplicity are crucial. This feature makes the UTx318M an excellent choice for diverse applications, from wildlife observation to security patrols.
Key Features
IR Resolution : 400×300 pixels for high-quality imaging
Lens Focal Length : 18mm for mid-range versatility
Thermal Sensitivity : ≤25mK for exceptional detection accuracy
Field of View (FOV) : 14.6° × 11° for targeted scanning
Range Finding : Stadiametric
Battery Life : 6+ hours of operation
Durability : IP67 waterproof and 2-meter drop resistance
Additional Features : Hot Trace, Wi-Fi Live Streaming
Frequently Asked Questions
What is the detection range of the UTx318M?
Detection range depends on the target size and thermal contrast. The UTx318M's specifications list the maximum detection range for a standard 1.7m × 0.5m target. Actual usable range for identification is typically 30-50% of the maximum detection distance.
Is the UTx318M waterproof?
The UTx318M carries an IP rating for dust and water resistance. Check the specifications tab for the exact IP rating. The device is designed for outdoor use in varying weather conditions.
What's included with the UTx318M?
The UTx318M ships with the monocular, carrying case, USB charging cable, lens cloth, and user manual. Check the specifications tab for the complete package contents.
Specifications
IR Resolution 400×300
NETD ≤ 25mK
Field of View 14.6° × 11°
Spectral Response 8 - 14µm
Pixel Pitch 12µm
Refresh Rate 50 Hz
Focus Manual Focus
Detection Range 944m
Digital Zoom 2x, 4x, 8x / 1.0 - 8x continuous
Image Modes Thermal
Image Format PNG
Video Recording Yes
Video Format MP4
WiFi Yes
Mobile App Thermal Xplorer (Android & iOS)
Interface USB-Type-C
Data Storage Built-in 16GB
Display Type OLED
Display Size 0.39in
Display Resolution 1024×768
Languages English, French, German, Spanish, Italian, Russian
Battery 3200 mAh detachable Li-ion battery (UT-M20)
Battery Life ≥ 4h (with Wi-Fi off)
Weight 357 g
Dimensions 160 × 71.5 × 38.5 mm
IP Rating IP67
Drop Rating 2m
