Dc Resistance (Re): 6.1 Ω Resonance Frequency (Fs): 41.1 Hz Equivalent Volume (Vas): 11.5 L Electrical Q Factor (Qes): 0.39 Mechanical Q Factor (Qms): 3.21 Total Q Factor (Qts): 0.35 Voice Coil Inductance (Le): 3.71 Mh Force Factor (Bl): 29.7 Na Moving Mass (Incl. Air Load) (Mms): 219.7 G Suspension Compliance (Cms): 0.07 Mm/N Sensitivity: 84.9 Db 1W / 1M
Box Recommendations:
Sealed: 0.5 Cu. Ft. Ported: 1.0 Cu. Ft. Displacement: 0.21 Cu. Ft. Depth: 7.007 In Outside Diameter: 10.94 In Cutout Diameter: 9.17 In Recommended Tuning: 32 Hz Recommended Port Area: 16 Sq. In
⚠️ WARNING (California Proposition 65): This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, please visit www.P65Warnings.ca.gov.
Frequently Asked Questions
Q: What are the dimensions of the Sundown Audio U-10 D4 subwoofer?A: The Sundown Audio U-10 D4 measures seven point zero one inches in depth, ten point ninety-four inches in outside diameter, and nine point seventeen inches in cutout diameter.
Q: What materials are used in the construction of this subwoofer?A: The Sundown Audio U-10 D4 is constructed with a cast aluminum frame, which enhances coil stability and increases mechanical excursion capability.
Q: What is the power rating of the Sundown Audio U-10 D4?A: The Sundown Audio U-10 D4 has a power rating of one thousand five hundred Watts RMS, making it suitable for high-performance audio systems.
Q: How do I install the Sundown Audio U-10 D4 subwoofer?A: To install the Sundown Audio U-10 D4, ensure you have a properly sized enclosure and connect the dual four-ohm voice coils to your amplifier according to the manufacturer's instructions.
Q: Is this subwoofer suitable for all vehicle types?A: Yes, the Sundown Audio U-10 D4 can be installed in various vehicle types, provided you have the appropriate space for the enclosure.
Q: What type of enclosure is recommended for this subwoofer?A: The recommended enclosure for the Sundown Audio U-10 D4 is either a sealed box of zero point five cubic feet or a ported box of one cubic foot.
Q: How do I clean and maintain the Sundown Audio U-10 D4?A: To clean the Sundown Audio U-10 D4, gently wipe the surface with a dry cloth. Avoid using water or harsh chemicals to prevent damage.
Q: Is the Sundown Audio U-10 D4 safe to use?A: Yes, the Sundown Audio U-10 D4 is safe to use when installed and operated according to the manufacturer's instructions.
Q: How do I store the Sundown Audio U-10 D4 when not in use?A: When not in use, store the Sundown Audio U-10 D4 in a dry, cool place to prevent damage from moisture and temperature fluctuations.
Q: Can I use this subwoofer for home audio systems?A: Yes, the Sundown Audio U-10 D4 can be used in home audio systems if the appropriate enclosure and amplification are provided.
Q: How does the Sundown Audio U-10 D4 compare to other subwoofers?A: The Sundown Audio U-10 D4 stands out due to its high power rating of one thousand five hundred Watts RMS and its advanced engineering features like the long pole-extension motor.
Q: What should I do if the subwoofer arrives damaged?A: If the Sundown Audio U-10 D4 arrives damaged, contact the retailer immediately to initiate a return or exchange process.
Q: What is the warranty on the Sundown Audio U-10 D4?A: The Sundown Audio U-10 D4 typically comes with a manufacturer warranty, which covers defects in materials and workmanship.
Q: What if I encounter issues during installation?A: If you encounter issues during installation, consult the user manual or contact customer support for troubleshooting assistance.
Q: Is the Sundown Audio U-10 D4 suitable for beginners?A: Yes, the Sundown Audio U-10 D4 can be suitable for beginners who are willing to learn about proper installation and audio setup.
