Im-Fp888Gw Series Is The Poe 8 Port Managed Outdoor Switch,&Nbsp;Comply With&Nbsp;Ieee802.3Af/At, Power On Poe Ip Cameras Through The Ethernet Cable, Simple Construction, Power&Nbsp;Range Up To 100 Meters, Operating Temperature-40 ? To + 75 ?, Meet Ip40 Protection Degree, And&Nbsp;Emc Industrial Grade Requirements, Din Rail Installation, Pass Through Dangerous Environmental&Nbsp;Certification And Comply With Fcc And Ce Standards. Ports: 1. Fiber Port: 8Pcs 1.25G Sfp Fiber Ports ( Without Sfp Transceivers) 2. Network Ports: 8Pcs 10/100/1000M Rj45 Ports With Poe At 30W (Without Power Adapter) 3. Managed Port: 1Pc Console Network Port&Nbsp; Managed Features: 1. 4Kv Ethernet Surge Protection, Adapt To A Harsh Outdoor Environment 2.&Nbsp;Support Ieee802.3Az Eee Management,&Nbsp;Optimize Power Consumption 3. Support Stp, Rstp, Mstp, Itu-T G.8032 Ethernet Protection Ring(Epr) 4.&Nbsp;Support Qos, Transport Classification Qos, Cos, Bandwidth Control&Nbsp;(Input/Output Direction), Storm Suppression, Differentiated Services 5.&Nbsp;Support Ieee802.1Q Vlan, Vlan Port, Based Mac Vlan, Ip Subnet Vlan,&Nbsp;Protocol Vlan, Vlan Convert, Mvr 6.&Nbsp;Support Dynamic Ieee802.3Ad Lacp Link Aggregation, Static Link Aggregation 7. Support Igmp, Mld Snooping V1/V2/V3, Igmp Filtrating/ Modulating, Igmp Searching 8. Safety: Based On Port And Mac Ieee802.1X, Radius, Acl, Tacacs+&Nbsp;,Http/Https, Ssl/Ssh V2 9. Support Cisco Like Cli, Web Management, Snmp V1/V2C/V3, Telnet 10. Support Software Upgrade Via Tftp And Http, Firmware Redundancy Prevents Upgrade From Failing 11.&Nbsp;Support Dhcp Client/Relay/Snooping/Snooping Option 82/Relay Option 82 12.&Nbsp;&Nbsp;Support Rmon, Mib Ii, Mirror Image, Event Log, Dns, Ntp/Sntp, Ieee802.1Ab Lldp 13.&Nbsp;&Nbsp;Support Ipv6 Telnet Server /Icmp V6, Snmp, Http, Ssh/Ssl, Ntp/Sntp,Tftp, Qos, Acl
⚠️ WARNING (California Proposition 65): This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, please visit www.P65Warnings.ca.gov.
Frequently Asked Questions
Q: What are the dimensions of the OLYCOM POE Switch?A: The dimensions of the OLYCOM POE Switch are six point twenty-two inches in length, four point fifty-two inches in width, and two point thirty-six inches in height.
Q: How many ports does this POE switch have?A: This POE switch has eight ports for Gigabit Ethernet and eight SFP slots.
Q: What is the power output for each POE port?A: Each POE port provides a power output of thirty watts.
Q: What is the operating temperature range of this switch?A: The operating temperature range is from negative forty degrees Celsius to positive seventy-five degrees Celsius.
Q: Is this switch suitable for outdoor use?A: Yes, this switch is designed for outdoor use and meets IP40 protection standards.
Q: How do I install the OLYCOM POE Switch?A: You can install the OLYCOM POE Switch using DIN rail mounting, which is included.
Q: Can I use this switch for my IP cameras?A: Yes, this switch can power POE IP cameras through the Ethernet cable.
Q: Does this switch support VLAN configuration?A: Yes, it supports IEEE802.1q VLAN configuration along with various types of VLANs.
Q: What features help protect against power surges?A: The switch includes four kV Ethernet surge protection to safeguard against power surges.
Q: What is the total power capacity of the switch?A: The total power capacity of the switch is two hundred forty watts.
Q: How do I maintain the OLYCOM POE Switch?A: To maintain the switch, ensure it is kept clean and protected from harsh environmental conditions.
Q: Is there a warranty for the OLYCOM POE Switch?A: Yes, it comes with a warranty, but the specifics may vary, so check with the manufacturer.
Q: What should I do if my switch arrives damaged?A: If your switch arrives damaged, contact customer support immediately for assistance with returns or exchanges.
Q: Can I perform a firmware upgrade on this switch?A: Yes, the switch supports firmware upgrades via TFTP and HTTP.
Q: What kind of customer support is offered?A: Lifetime technical support is provided for the OLYCOM POE Switch.
