Introducing the Nooelec SAWbird+ ADS-B Dual-Channel Low Noise Amplifier (LNA), a high-performance solution designed to enhance weak signals in ADS-B and UAT applications. This premium module is ideal for aviation enthusiasts and professionals looking to improve their plane tracking capabilities.
The Nooelec SAWbird+ ADS-B LNA is meticulously engineered to deliver exceptional performance. With center frequencies of 1090MHz for ADS-B and 978MHz for UAT, this module provides a remarkable gain of approximately +35 dB for each channel, while maintaining an ultra-low noise figure of less than 0.9dB. The high-quality materials and robust design ensure durability and reliability in various environments, making it a top choice for signal enhancement.
Key Features:
Significantly increases signal-to-noise ratio (SNR), enhancing plane tracking capabilities.
Industry-lowest noise figure of 0.9dB or lower, providing superior performance compared to competing products.
Fully assembled module pre-installed in a sleek black custom aluminum enclosure for durability.
Includes two male to male SMA adapters and a micro USB to DC barrel connector adapter for versatile power options.
Exceptional out-of-band rejection levels of +85dB, ensuring cleaner signals for improved reception.
Bias tee power options available (3V-5V DC) with a current availability of 140mA or higher.
Backed by a generous 2-year warranty, ensuring peace of mind with your purchase.
The Nooelec SAWbird+ ADS-B LNA is perfect for aviation enthusiasts, hobbyists, and professionals seeking reliable signal enhancement for flight tracking systems. Its unique combination of high gain, low noise figure, and exceptional construction makes it an essential tool for anyone involved in surveillance, monitoring, or communication within the aviation industry. Enhance your reception range and experience unparalleled signal quality with the Nooelec SAWbird+ ADS-B LNA, and take your plane tracking to new heights.
⚠️ WARNING (California Proposition 65): This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, please visit www.P65Warnings.ca.gov.
Frequently Asked Questions
Q: What are the dimensions of the Nooelec SAWbird+ ADS-B module?A: The dimensions are one point two six inches in length, zero point eight three inches in width, and zero point four seven inches in height.
Q: What materials are used in the Nooelec SAWbird+ ADS-B module?A: The materials used are Nooelec materials, ensuring quality and durability.
Q: What is the power input range for the Nooelec SAWbird+ ADS-B?A: The recommended power input range is three to five volts DC through the SMA output port.
Q: How do I install the Nooelec SAWbird+ ADS-B amplifier?A: To install, connect the SMA output port to your SDR device and power it using one of the provided options.
Q: Is the Nooelec SAWbird+ ADS-B suitable for beginners?A: Yes, it can be used by beginners, but proper setup and adjustment of gain levels are essential for optimal performance.
Q: Can I use the Nooelec SAWbird+ ADS-B with any SDR?A: No, it is recommended to use a bias tee capable SDR for best results.
Q: How do I keep the Nooelec SAWbird+ ADS-B module in good condition?A: Keep the module dry and store it in a cool place when not in use to ensure longevity.
Q: What is the warranty on the Nooelec SAWbird+ ADS-B module?A: It comes with a generous two-year warranty for peace of mind.
Q: What should I do if the Nooelec SAWbird+ ADS-B module arrives damaged?A: Contact customer support immediately to initiate a return or exchange process.
Q: What is the noise figure of the Nooelec SAWbird+ ADS-B?A: The module features an ultra-low noise figure of less than zero point nine decibels.
Q: How much gain does the Nooelec SAWbird+ ADS-B provide?A: It provides approximately thirty-five decibels of gain for each channel.
Q: Can I power the Nooelec SAWbird+ ADS-B using a micro USB?A: Yes, you can power it through the micro USB port if bias tee power is unavailable.
Q: What is the out-of-band rejection level of the Nooelec SAWbird+ ADS-B module?A: It features exceptional out-of-band rejection levels of eighty-five decibels.
Q: Is the Nooelec SAWbird+ ADS-B module suitable for outdoor use?A: Yes, it is designed for outdoor applications like airplane tracking.
Q: How does the Nooelec SAWbird+ ADS-B compare to other amplifiers?A: It drastically outperforms other low-cost ADS-B amplifiers with its industry-leading noise figure and substantial gain.
