Frequently Asked Questions

• Q: What are the dimensions of the GIGABYTE Z690 AORUS Elite AX motherboard? A: The dimensions are thirteen point nineteen inches in length, ten point sixty-three inches in width, and three point fifteen inches in height.
• Q: What type of socket does this motherboard use? A: This motherboard uses the Intel LGA 1700 socket, which supports both twelfth and thirteenth generation Intel Core processors.
• Q: What memory type does the GIGABYTE Z690 AORUS Elite AX support? A: It supports dual channel non-ECC unbuffered DDR5 memory.
• Q: How many M.2 slots does this motherboard have? A: The GIGABYTE Z690 AORUS Elite AX includes four M.2 slots for NVMe PCIe storage.
• Q: What is the maximum power design of this motherboard? A: This motherboard features a commanding power design with a sixteen plus one plus two twin hybrid digital VRM design.
• Q: What connectivity options are available on this motherboard? A: It offers PCIe five point zero, SuperSpeed USB three point two Gen two by two Type-C, and two point five gigabit Ethernet.
• Q: How do I install the GIGABYTE Z690 AORUS Elite AX motherboard? A: To install, place it in the case, align it with the standoffs, and secure it with screws while connecting the power supply and peripherals.
• Q: Is this motherboard compatible with Intel cooling brackets? A: Yes, it is only compatible with Intel LGA 1700 cooling brackets.
• Q: How do I update the BIOS on this motherboard? A: You can update the BIOS using the Q-Flash Plus feature without needing to install the CPU, memory, or GPU.
• Q: What features enhance thermal performance on this motherboard? A: It includes fully covered MOSFET heatsinks and an integrated I/O shield for improved thermal management.
• Q: What audio capabilities does this motherboard have? A: This motherboard features Realtek audio codec supporting two, four, five point one, and seven point one channel audio.
• Q: How can I customize the LED lighting on this motherboard? A: The motherboard supports RGB FUSION two point zero, allowing customization of addressable LED and RGB LED strips.
• Q: What should I do to clean the GIGABYTE Z690 AORUS Elite AX? A: To clean, gently wipe the surface with a dry microfiber cloth; avoid using liquids that may damage the components.
• Q: What is the warranty period for this motherboard? A: The warranty period typically lasts for three years from the date of purchase, but check with the retailer for specifics.
• Q: What if my motherboard arrives damaged? A: If it arrives damaged, contact the retailer’s customer service for return or replacement options as per their policy.
