DC 3V-6V bis 400kV 400000V 1000KV Boost Step up Power Module High Voltage Generator Generator 1000kmer Booster Module 3-6V 400KV - 1000KV
$3.37
SPECIFICATIONS
Application: Computer
Brand Name: NONE
Choice: yes
Condition: New
Dissipation Power: n/a
High-concerned chemical: none
Model Number: DC 3V-6V Bis 400kV 400000V
Operating Temperature: n/a
Origin: Mainland China
Supply Voltage: n/a
Type: Module
is_customized: Yes
Description:
input voltage: DC 3 V to 6 V
Input current: 2 A - 5 A
High pressure type: the type of pulse current
Output voltage: 400000 v(Please pa y attention to safety)
High pressure discharge distance between: 10 mm - 20 mm
The output high voltage wire length: 100 mm
Input power cord length: 100 mm (the red line is positive)
Wiring:
Red and green power connection red line:"+" green line "-"
output : the other side ,same color cable
Please notice:
the high-voltage module should avoid the use of electricity in high voltage no-load . (Power must be adjusted to a suitable distance to the high-voltage output line , battery capacity is proportional to the distance and the use of the high-pressure arc ( not a voltage as high as possible , you must provide enough current ) . Experimental test of the arc distance from short to long , Do not exceed the maximum arc distance electricity, energy can not be released due to high pressure , can easily damage the module. )
Work: intermittent , continuous work does not allow more than 1 minute and the output side does not allow shorting . Improper voltage and long working hours easily damaged module
Package included:
1PCS x DC 3v-6v to 400kV 400000V Boost Step-up Power Module High-voltage Generator
High voltage generator 3.7-7.4V 1000KV
This module is the finished module of high voltage inverter, transformer/booster for scientific small production
Input terminal Input :DC3.7V-7.4V
After the voltage can be obtained at the output end of tens of thousands of volts of DC high voltage
It can be used for middle school popular science experiments, electronic instruments, negative ion generators, and scientific small production
Voltage source use
The module is made of Tesla coil principle, output current, small size,
High efficiency
The circuit is simple (just connect the switch, the battery can be) and the discharge intensity is fierce. Pay attention to this style
Not high temperature arc, can not light smoke point paper oh ~
Module model :MC-901.
Input voltage :3.7V-7.4V, input current :0.5A-1A, input line length: 9cm left
Right, high voltage type: pulse DC type
Output voltage :800KV-1000KV(please pay attention to safety when using)
Output current :0.5A-1A
Output line length: about 16 cm
High voltage electrode discharge distance: 1.5cm - 2cm
Power discharge time :10 seconds
Product usage: The module is divided into input end and output end, red and green line is the input end, red positive green
Negative, the output end is two high-voltage lines of the same color, and the input end can be connected to the battery to produce high
Pressure arc.
Please strictly follow the use method and precautions to operate the module, otherwise it is easy to damage the module!
About the input power supply: you can use a single 3.7V lithium battery or two in series, such as 18650 electricity
Pool, idle mobile phone battery (to remove the protection board, the recommended capacity is more than 2000mAh)
Or nickel-cadmium/nickel-metal hydride battery pack, 4V or 6V lead-acid battery, etc. (6V battery can achieve the best effect)
Notes on module use:
1, the high voltage module should avoid the use of high voltage no-load power, power must be adjusted before the high voltage cable
End suitable distance, the high-voltage line arc distance is proportional to the battery voltage and capacity used.
2, test arc distance from short to long experiment, power is strictly prohibited beyond the longest pull arc distance
Because the high pressure energy can not be released, it is easy to damage the module.
3, the power of the module is large, the internal heat dissipation is not suitable, so it can not work for a long time, generally 10 seconds
Inside is fine.
4. The way to determine whether the battery capacity can drive the maximum power output is to measure the electricity when the arc is pulled
The pool voltage. If it is around 6V, it can output the maximum power. 5, small capacity lithium two
The section series is 7.2V, and the measured voltage in the arc pulling state has fallen to about 4V, and the capacity is smaller
The lower the voltage is pulled. Therefore, it is recommended to use more than 2000MA lithium, and the conditions are best
Batteries above 4000MA.
