Easy To Use Guide 1.Control Mode: Dmx, Master Slave Mode, Auto Mode, Sound Mode, If You Bought More Than One, You Can Use Master Slave Mode, You Need Let Them Serial Connection (You Need To Prepare Signal Line By Yourself), From The Second To End All Set To A001,Then You Can Set The First One On Any Model , The Latter Will Follow The First One. 2.Of Cause, It With Dmx512, If You Have Dmx Console, You Can Controller It By Console. Set The Display Address On A001 Or A017, Or A033... A(1+16+16....) So Ok. 3.Factory Default Setting Is Sound2, When You Let Power On, It Will Be Green First, Then Auto Change Color By Sound, You Can Press Up Or Down To Choose Run1,Run2......, Each Time, You Need Press Enter After You Choose Any Features, This Is Very Easy .We Noticed That Most Buyers Use Automatic Or Sound Features. 4. If You Want Stay In Single Color, But You Have Not Dmx Console, You Need To Set Menu Window Like This: Press: Menu---Colr---Enter, Up Or Down Change The Rgby Number, Each Time, You Need Press Enter Again Stay In Red-------R255-----G000-----B000-----Y000 Stay In Green----R000-----G255-----B000-----Y000 Stay In Blue------R000-----G000-----B255-----Y000 Stay In White----R000-----G000-----B000-----Y255 Note: Factory Default Setting Is: R255,G255,B255,Y255 (Y=W) Voltage: Ac 90-240V, 50-60Hz Power Consumption: 12W Lamp: 12W (4 In 1) Color: R.G.B.W Control Mode: Dmx, Master Slave Mode, Auto Mode, Sound Mode Channel: 6 Ch Display: Digital Screen Carton Size: 160X160X90Mm N.W.: 0.4Kg G.W.: 0.49Kg The Product Comes With Us Type Of Power Plug.
⚠️ WARNING (California Proposition 65): This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, please visit www.P65Warnings.ca.gov.
Frequently Asked Questions
Q: What is the power consumption of the pinspot light?A: The power consumption is twelve watts. This makes it energy-efficient while providing bright lighting for various events.
Q: What are the dimensions of the pinspot light?A: The dimensions are six point three inches in length, six point three inches in width, and three point five four inches in height. This compact size makes it easy to install in various settings.
Q: What voltage does the pinspot light operate on?A: It operates on a voltage range of ninety to two hundred forty volts. This versatility allows it to be used in different countries with varying power supplies.
Q: How do I control the pinspot light?A: You can control it using DMX, master-slave mode, auto mode, or sound mode. Each mode offers different lighting effects suitable for various occasions.
Q: Can you use multiple pinspots together?A: Yes, you can connect multiple pinspots using master-slave mode. This allows you to control them simultaneously for synchronized light shows.
Q: How do I change the color settings on the pinspot light?A: To change color settings, press menu, select 'colr', and then adjust the RGBY numbers. Each adjustment requires pressing 'enter' to confirm the changes.
Q: What kind of events is the pinspot light suitable for?A: It is ideal for weddings, clubs, DJ shows, discos, bars, home parties, and ballrooms. The versatile lighting enhances the ambiance of any event.
Q: What type of power plug does the pinspot light come with?A: The product comes with a US type power plug. Ensure you have the appropriate adapter if used in other regions.
Q: How do I install the pinspot light?A: Installation is straightforward, thanks to its bracket design. It can be easily mounted on walls or stands for optimal lighting effects.
Q: What safety features does the pinspot light have?A: The pinspot light has built-in safety features to prevent overheating. It is designed for stable operation and adheres to electrical safety standards.
Q: What should I do if the light doesn't turn on?A: If the light doesn't turn on, first check the power connection. Ensure the voltage is correct and the power plug is securely connected.
Q: Can I return the pinspot light if I am not satisfied?A: Yes, you can return the pinspot light within the return policy period if you are not satisfied. Check the specific return conditions for more details.
Q: How should I clean the pinspot light?A: To clean the pinspot light, use a soft, dry cloth. Avoid using harsh chemicals or water to prevent damage to the electrical components.
Q: Is the pinspot light suitable for outdoor use?A: No, the pinspot light is designed for indoor use. Exposure to moisture and outdoor elements can damage its electrical components.
Q: What is the weight of the pinspot light?A: The net weight is zero point four kilograms, and the gross weight is zero point four nine kilograms. This lightweight design makes it easy to transport and set up.
Q: Does the pinspot light come with a warranty?A: Yes, the pinspot light typically comes with a manufacturer's warranty. Check the warranty details for duration and coverage specifics.
