1.3 Inch Oled Module Witte Kleur 128X64 Oled Lcd Led Display Module 1.3 Iic I2C Spi Communiceren Voor Arduino Diy kit
Free Standard Shipping Across USA
Vendor: Electroeshop
Type:
Sku: 14:10#4P White
Availability: In Stock
Couldn't load pickup availability
Guarantee safe checkout
Sold by Electroeshop, an authorized reseller.
Returns accepted within 30 days | support@electroeshop.com
Shipping Information
- Free Standard Shipping — United States only
- Processing Time: 3–5 business days
- Estimated Delivery: 6–10 business days after dispatch
- Double-boxed, fully insured & discreetly packaged
- Tracking number sent via email once dispatched
Returns & Refund
Returns accepted within 30 days of delivery.
Damaged or Defective Item
Free return shipping + replacement or full refund
Wrong Item Received
Free return shipping + replacement or full refund
Change of Mind
Return shipping at customer's expense · 25% restocking fee applies
All returns require a Return Authorization (RA) number before sending.
View Full Return & Refund Policy
1.3 Inch Oled Module Witte Kleur 128X64 Oled Lcd Led Display Module 1.3 Iic I2C Spi Communiceren Voor Arduino Diy kit - 4P White
$3.68
SPECIFICATIONS
Brand Name: EQV
Choice: yes
Display Mode: 1.3 Inch Oled Module
High-concerned chemical: none
Model Number: 1.3 Inch Oled Module
Origin: Mainland China
Resolution: 128*160
Type: OLED
is_customized: Yes
semi_Choice: yes
Product Description
1.3-inch OLED, high resolution: 128X64 (same resolution as 12864, high PPI)
Super large viewing angle: greater than 160 °(the screen with the largest viewing angle in the display screen)
Ultra low power consumption: normal display 0.06w (far lower than TFT display)
Wide voltage supply (3V ~ 5V), compatible with 3.3V and 5V level logic, without level conversion chip
The default SPI interface (IIC interface can be changed), only 5 IOS are needed to light up easily
The working temperature range is industrial grade (- 20 ℃ ~ 70 ℃)
Military grade process standard, long-term stable work
Provide rich routines, provide the underlying driver technical support
Product Parameters
Name |
Parameter |
Display Color |
white/blue |
SKU |
MSP130W / MSP130B |
Screen Size |
1.3(inch) |
Screen Type |
OLED |
Driver IC |
SH1106 |
Resolution |
128*64 (Pixel) |
Module Interface |
4-wire SPI interface |
Active Area |
29.42x14.7(mm) |
Module PCB Size |
33.50x35.40(mm) |
Operating Voltage |
3.3V~5V |
Logic IO port voltage |
3.3V(TTL) |
Power Consumption |
TBD |
Rough Weight(Package containing) |
10(g) |
Interface Definition
Module Pin |
Pin description |
GND |
OLED power ground |
VCC |
OLED power positive (3.3V~5V) |
CLK |
SPI bus clock signal of OLED display module |
MOSI |
SPI bus write data signal of OLED display module |
RES |
Reset control signal of OLED display module |
DC |
Command / data selection control signal of OLED display module |
CS |
Chip selection control signal of OLED display module |
Product Description
1.3 inch OLED screen with black and white or black and blue color display
128x64 resolution for clear display and high contrast
Large viewing angle: greater than 160° (one screen with the largest viewing angle in the display)
Wide voltage supply (3V~5V), compatible with 3.3V and 5V logic levels, no level shifting chip required
With IIC bus, only a few IOs can be used to light up the display
Ultra-low power consumption: normal display is only 0.06W (far below the TFT display)
Military-grade process standards, long-term stable work
Provides a rich sample program for STM32, C51, Arduino, Raspberry Pi and MSP430 platforms
Provide underlying driver technical support
Product Parameters
Name |
Parameter |
Display Color |
white/blue |
SKU |
MC130GW/MC130GB |
Screen Size |
1.3(inch) |
Screen Type |
OLED |
Driver IC |
SH1106 |
Resolution |
128*64 (Pixel) |
Module Interface |
IIC interface |
Active Area |
29.42x14.7(mm) |
Touch Screen Type |
have no touch screen |
Touch IC |
have no IC |
Module PCB Size |
33.50x35.40(mm) |
Visual Angle |
>160° |
Operating Temperature |
-20℃~60℃ |
Storage Temperature |
-30℃~70℃ |
Operating Voltage |
3.3V~5V |
Power Consumption |
TBD |
Rough Weight(Package containing) |
10(g) |
Interface Definition
|
NOTE:
1.This module supports IIC slave device address switching (shown in red box in Picture 4), as follows:A.Solder the 0x78 side resistance, disconnect the 0x7A side, then select the 0x78 slave address (default);B.Solder the 0x7A side resistance, disconnect the 0x78 side, then select the 0x7A slave address;2.The hardware switches the IIC slave device address, and the software also needs to be modified accordingly.For details, see the test program description document or the user manual..
Number |
Module Pin |
Pin description |
1 |
GND |
OLED power ground |
2 |
VCC |
OLED power positive (3.3V~5V) |
3 |
SCL |
OLED IIC bus clock signal |
4 |
SDA |
OLED IIC bus data signal |
