Warm Tips 1.Without A Power Adapter, Eq5-Tone Needs To Be Powered By Separate Usb Power Supply. Don'T Use The Usb Port Of Computers Or Share The Power Supply With Audio Source, Otherwise Common Ground Noise Will Be Caused. 2.Stereo Rca And 3.5Mm Aux Input Are In Parallel, Two Inputs And Outputs Will Work Simultaneously, So To Avoid Signal Mixing, Please Don'T Connect Rca And 3.5Mm Aux Input At The Same Time. 3.Eq5-Tone Can Input And Output Audio Signal Without Power Supply In Bypass Mode. However, If The Signal Hasnt Been Preamplified, The Vu Meters Will Not Function. Parameters Brand: Douk Audio Model: Eq5-Tone Audio Input: Bluetooth / Stereo Rca / 3.5Mm Aux Audio Output: Stereo Rca / 3.5Mm Aux Eq Bands:75Hz / 400Hz / 800Hz / 4Khz /10Khz Bypass Function: Support Balance Adjustment Of L/R Channel: Support Input Impedance: 50Ko Output Impedance: 15O Frequency Response: 5Hz-20Khz Thd: 0.003%@1 Khz Working Voltage: Dc 5V (=500Ma) Power Interface: Usb (Type-C) Diameter Of Vu Meter: 45Mm Dimensions(W*D*H): 164*108*82Mm / 6.46*4.25*3.23In Package Dimensions(W*D*H): 210*L85*100Mm/8.27*7.28*3.94In Net Weight:730G /1.61Lb Package Weight:1.0Kg/2.20Lb Packing List 1*Eq5-Tone Equalizer 1*Usb Cable (Type-C) 1*User Manual 1*Screwdriver
⚠️ WARNING (California Proposition 65): This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, please visit www.P65Warnings.ca.gov.
Frequently Asked Questions
Q: What are the dimensions of the Douk Audio 5 Band Equalizer?A: The dimensions are six point four six inches by four point two five inches by three point two three inches.
Q: What is the weight of the Douk Audio EQ5?A: The net weight is one point six one pounds.
Q: What inputs does the EQ5 support?A: The EQ5 supports Bluetooth, stereo RCA, and three point five millimeter AUX inputs.
Q: What is the frequency response range of the EQ5?A: The frequency response range is five Hertz to twenty kilohertz.
Q: What voltage does the Douk Audio EQ5 require?A: The working voltage requirement is DC five volts.
Q: How do I connect the EQ5 to my devices?A: You can connect the EQ5 using Bluetooth, stereo RCA, or three point five millimeter AUX cables.
Q: Can I use the EQ5 without a power supply?A: Yes, the EQ5 can operate in bypass mode without a power supply, but without preamplification.
Q: How do I adjust the audio settings on the EQ5?A: You can adjust the audio settings using the five band equalizer and balance controls.
Q: Is the EQ5 portable for travel?A: Yes, the EQ5 features a compact design and requires DC five volts, making it easy to carry.
Q: How do I maintain the Douk Audio EQ5?A: To maintain the EQ5, ensure it is kept in a dry place and avoid exposing it to extreme temperatures.
Q: Is the EQ5 safe to use with my computer?A: Yes, but do not use the USB port of your computer as a power supply to avoid ground noise.
Q: Does the EQ5 have a warranty?A: Yes, the EQ5 typically comes with a standard manufacturer's warranty.
Q: What should I do if my EQ5 arrives damaged?A: Contact customer support for return instructions and possible replacement options.
Q: Can I use the EQ5 with different audio sources at the same time?A: Yes, both stereo RCA and three point five millimeter AUX inputs can work simultaneously.
Q: What enhancements does the upgraded version of EQ5 Pro offer?A: The upgraded version offers enhanced frequency range, improved low frequency performance, and VU meter adjustments.
